Bar Feeders


The Minuteman 320 SE has a double pusher, dual anti-vibration devices, a gripper device that holds and inserts the new bar into the bar collet and is also used to extract the remnant, a rotating tip & collet, and a sync device.
Edge Technologies brand logo
Minuteman 320 SE Bar Feeder
3.0mm - 20mm | .118" - 1.062"
Bar Length: 6', 12'
Headstock Type: Fixed, Sliding
The FMB Turbo 2-20, available in either 6' or 12' configuration, is an automatic bar feeder for processing bars in the diameter range of 2-20 mm in lengths from 6’ to 14’ on CNC lathes. Equipped with a Swiss type headstock synchronization device, peck drilling and threading on small diameter bars is simple and done with high-tolerances. The Turbo 2-20 is designed to automatically feed round, square or hexagonal bars into CNC lathes.
FMB brand logo
Turbo 2-20 Bar Feeder
2.0mm - 20mm | 0.078" - 0.787"
Bar Length: 6', 12'
Headstock Type: Fixed, Sliding
The Micromag 20 Bar Feeder is an automatic magazine style bar feeder equipped with a single bar pusher design that can reduce bar change time by 50%, a feed mechanism that is automatically pulsed to ensure the profiled material is successfully located in the lathe collet / chuck, length monitoring and quick-change guide channels.
FMB brand logo
Micromag 20 Bar Feeder
0.8mm - 20mm | .031" - .787"
Bar Length: 6', 12'
Headstock Type: Fixed, Sliding
The FMB Turbo 3-26, available in either 6' or 12' configuration, is a magazine style automatic bar feeder designed for feeding round, square and hexagonal bar material into all types of sliding, fixed, CNC, or cam operated lathes. Quick change polyurethane guide channels allow for quiet operation of the Turbo 3-26 at high RPM while feeding round, square or hex bar stock. The Turbo 3-26 is compatible with all types of sliding or fixed, CNC or cam operated lathes with spindle bores up to 38mm.
FMB brand logo
Turbo 3-26 Bar Feeder
3.0mm - 26mm | 0.118" - 1.023"
Bar Length: 6', 12'
Headstock Type: Fixed, Sliding
The FMB Turbo 3-38, available in 6' or 12' configurations, is an magazine type, automatic bar feeder designed for feeding round, square and hexagonal bar material into all types of sliding, fixed, CNC, or cam operated lathes. Quick change polyurethane guide channels allow for quiet operation at high RPM while feeding round, square or hex bar stock.
FMB brand logo
Turbo 3-38 Bar Feeder
3.0mm - 38mm | 0.118 - 1.500"
Bar Length: 6', 12'
Headstock Type: Fixed, Sliding
The Turbo 5-55, 5-65, and 8-80 are compatible with all kinds of fixed headstock lathes. Swiss type synchronization device is also available.
FMB brand logo
Turbo 5-55 Bar Feeder
5.0mm - 55mm | 0.196" - 2.165"
Bar Length: 6', 12'
Headstock Type: Fixed, Sliding
The FMB Turbo 5-65, available in 6' or 12' configurations, is an automatic bar feeder for processing bars in the diameter range of 5-65mm and in lengths up to 3200mm, 3800mm, or 4200mm on machine tools. Quick change polyurethane guide channels allow for quiet operation at high RPM while feeding round, square or hex bar stock.
FMB brand logo
Turbo 5-65 Bar Feeder
5.0mm - 65mm | 0.196" - 2.559"
Bar Length: 6', 12'
Headstock Type: Fixed, Sliding
