Schlenker Collets & Guide Bushings

Superior Quality Schlenker offers a complete line of superior quality work-holding collets and guide bushings for applications requiring high precision and accuracy. They are simply the best you can buy. Here is a sample of what Schlenker offers:

  • Special solutions / customized solutions
    • S-Slot collets
    • Long-nose guide bushings
    • Overgripping collets
    • Step collets
    • Guide bushings with extended inserts
    • Serrated clamping collets
  • Collets
    • Pressure collet chucks
    • Draw-In collets
    • Dead-Length collets
    • Pick-off collets
    • ER collets
  • Guide bushings
    • Adjustable guide bushings
    • Flexible guide bushings
    • S-Slot guide bushings
    • SB Guide bushings (for Titanium)
    • BL guide bushings
  • Clamping sleeves
  • Bearings
  • Spindle reducer

CONTACT SCHLENKER SALES: (314)810-3959

Schlenker Collets and Guide Bushings Catalog

See line-up of Schlenker Collets & Bushings:

Schlenker collets collection 1

Collets


Schlenker over-grip collet

Overgrip Collet

  • For gripping over a large surface to a smaller diameter
  • Used on a pick-off spindle when it is required to clear a shoulder and grip on a smaller diameter beyond, such as screws or bolts. (over the shoulder collet)
Schlenker extended-nose collet

Extended Nose Collet

Featuring the Schlenker S-Slot Design

  • No debris in the collet, since it completely closes
  • Clamping without marks on the material
  • Concentricity of the collet <0.005 mm
  • Deviations of the material can be by-passed
  • Ideal for square- and hex material
  • High and even tension
  • Easy to clean after the use
  • Assists with tool clearance in work envelope
Schlenker sealed bushing

Fully Sealed Collet

Brass | Synthetic | Aluminum

  • Prevents stains on the material
  • Inserts are exchangeable after wearing and tearing
  • Ideal for material sensitive to scratching and excellent for smooth pick-up

Bushings


Schlenker long-nose bushing

Long Nose Guide Bushings

  • Improved workholding stability by shifting guide area forward
Image of Schlenker bushings

Guide Bushing with Extended HM Insert

  • Guiding surface up to 40mm
  • Capable of machining a larger part
  • High concentricity
Schlenker bushing

SB Guide Bushings

  • For use with materials with hard gliding properties – such as titanium
  • Prevents welding together of guiding area and part
  • Precision workholding ideal for swiss machines

Schlenker Lathe Collets and Guide Bushings

Download Schlenker Catalog

To order please call our Sales Department at (314) 692-8388 or e-mail




CONTACT SCHLENKER SALES: (314)810-3959
