The Ranger 112 is a magazine style automatic bar feeder designed for feeding round, square and hexagonal bar stock in lengths up to 12’5″, in a diameter range of 1.5-15mm, into CNC lathes.
The Ranger 112 comes equipped with a Mistubishi controller and belt drive standard. It also features dual anti-vibration devices that stabilize the bar stock at two critical points between the guide channel and lathe spindle maximizing RPM potential. The polyurethane guide channels increase strength and stability.
![EDGE Brand Logo](https://edgetechnologies.com/wp-content/uploads/2018/11/edge-brand-bar-feeder-logo.png)
Ranger 112 Bar Feeder
Make: EDGE | Bar Length: 12' | Bar Diameter: 0.059” – 0.59”
Features: Ranger 112 Bar Feeder
- Bar diameter capacity: 1.5 mm to 15 mm (.059” to .594”)
- Scroll-fed magazine — hold 16 bars
- Double pusher, space saving design
- Polyurethane Quick Change guide channel — noise & vibration dampening
- Hydrodynamic support via high volume oil flow into channels
- Mitsubishi motion control — dependable and user friendly, allows easy bar feeder parameter changes-belt drive unit
- Dual anti-vibration devices—one internal to the bar feeder, the other mounted between the telescopic nose and the lathe headstock
- (1) Guide channel set to be chosen by customer. Several sizes to choose from, each handling a specific stock range. See chart below (spindle liner required if channel set is not lathe’s max capacity)
- (1) Standard telescoping front nose matched to the guide channel set
- (1) O.D. bar stock collet (to be chosen by customer, specific collet needed for each stock diameter)
- Swiss headstock synchronization device
- Automatic remnant retraction, self centering gripper
- Custom lathe cable and interface plugs
Technical Specifications: Ranger 112 | |
---|---|
Bar diameter range: | 1.5 mm to 15.0 mm (.059” to .594”) |
Maximum bar length: | 3800 mm (12 feet 5 inches) |
Maximum remnant length: | 420 mm (16.500”) |
Magazine rack capacity: | Scroll-type holds 16 bars |
Bar loading cycle time: | 30 seconds for 12-foot bar |
Feed force (pusher torque): | max 450 N, adjustable |
Forward feed rate: | 600 mm/minute max, adjustable |
Return feed rate: | 1000 mm/minute max |
Power consumption: | 1.5 kW |
Operating voltage: | 230V/60Hz |
Oil capacity: | 46 liters (12 gallons) |
Oil viscosity: | ISO 100 cST |
Compressed air supply: | 6 bar (90 psi) |
Compressed air consumption: | approx. 8 liters per loading cycle |
Machine weight: | 1250 lbs |
Reversible Configuration | Reversable to load from front or rear |
Channel | Pusher Ø | Min | Max | Max Bar With Remnant Ejection |
---|---|---|---|---|
8 | 7.5 | 1.5mm (.059”) | 6.4mm (.250”) | 7mm (.275”) |
11 | 10 | 2mm (.078”) | 9mm (.354”) | 10mm (.393”) |
14 | 12 | 3.2mm (.125”) | 11mm (.437”) | 13mm (.512”) |
16 | 15 | 5mm (.196”) | 12.7mm (.500”) | 15mm (.594”) |
